Specifications
Hardware Specifications
10/5/2.5/GE RJ45 or 10GE/GE SFP+/
SFP Shared Media pairs 2
GE RJ45 Internal Ports 8
Wireless Interface –
USB Ports 1
Console (RJ45) 1
Internal Storage –
Trusted Platform Module (TPM) yes
Bluetooth Low Energy (BLE) yes
System Performance — Enterprise Traffic Mix
IPS Throughput 4.5 Gbps
NGFW Throughput 2.5 Gbps
Threat Protection Throughput 2.2 Gbps
System Performance and Capacity
Firewall Throughput
(1518 / 512 / 64 byte UDP packets) 28 / 28 / 27.9 Gbps
Firewall Latency (64 byte UDP packets) 3.23 μs
Firewall Throughput
(Packets Per Second) 41.85 Mpps
Concurrent Sessions (TCP) 1.5 M
New Sessions/Second (TCP) 124 000
Firewall Policies 5000
IPsec VPN Throughput (512 byte) 25 Gbps
Gateway-to-Gateway IPsec VPN
Tunnels 200
Client-to-Gateway IPsec VPN Tunnels 2500
SSL-VPN Throughput 1.4 Gbps
Concurrent SSL-VPN Users (Recommended Maximum, Tunnel Mode) 200
SSL Inspection Throughput (IPS, avg. HTTPS) 2.6 Gbps
SSL Inspection CPS (IPS, avg. HTTPS) 1400
SSL Inspection Concurrent Session
(IPS, avg. HTTPS) 300 000
Application Control Throughput
(HTTP 64K) 6.7 Gbps
CAPWAP Throughput (HTTP 64K) 23.6 Gbps
Virtual Domains (Default / Maximum) 10 / 10
Maximum Number of FortiSwitches
Supported 24
Maximum Number of FortiAPs
(Total / Tunnel Mode) 96 / 48
Maximum Number of FortiTokens 500
High Availability Configurations Active-Active, Active-Passive, Clustering
Dimensions
Height x Width x Length (inches) 1.65 x 8.5 x 7.0
Height x Width x Length (mm) 42 x 216 x 178
Weight 2.47 lbs (1.12 kg)
Form Factor Desktop
Operating Environment and Certifications
Input Rating 12V DC, 5A (dual redundancy optional)
Power Required (Redundancy Optional) Powered by up to 2 External DC Power Adapters (1 adapter included), 100–240V AC, 50/60 Hz
Power Supply Efficiency Rating 80Plus Compliant
Power Required (Redundancy Optional) Powered by up to 2 External DC Power Adapters (1 adapter included), 100–240V AC, 50/60 Hz
Maximum Current 115Vac/0.4A, 230Vac/0.2A
Power Consumption
(Average / Maximum) 19.9 W / 20.53 W
Heat Dissipation 70.0 BTU/hr
Operating Temperature 32°–104°F (0°–40°C)
Storage Temperature -31°–158°F (-35°–70°C)
Humidity 10%–90% non-condensing
Noise Level 21.73 dBA
Operating Altitude Up to 10 000 ft (3048 m)
Compliance FCC, ICES, CE, RCM, VCCI, BSMI, UL/cUL, CB
Certifications USGv6/IPv6
